Oil & Gas sand control screens

Sand control screens QC: wire wrap, direct wrap, wedge wire — every slot measured.

Oil & gas is where CTRL+ optical metrology earned its reputation in sand control screens inspection. Wire wrap screens, direct wrap screens, wedge wire filter screens, slotted liners, pre-pack and standalone sand control screens — every one of them must hold up downhole, and screen failure is not an option.

Context

The sand control screens market we built for

Sand control completions are the most demanding measurement environment in industrial filtration. Wire wrap, direct wrap and wedge wire filter screens carry slot openings of a few hundred microns that must hold under pressure cycling, abrasion and erosion for years. A single defective sand control screen can shut down a well for days, and rework subsea is rarely possible.

Challenge

Why traditional sand control screens QC fails

Manual feeler gauges drift between operators. Lab benches are too far from the wire wrap and wedge wire screens production line, too slow, and only sample-checked. Suppliers ship sand control screens with a paper certificate that says nothing about the worst slot in the batch. End-users discover defects only at deployment.

Solution

How CTRL+ inspects every wire wrap and wedge wire screen

Optical metrology measures every slot, on every sand control screen — wire wrap, direct wrap, wedge wire filter screen or prepack. Production lines ship a real quality certificate aligned with ISO 17824 (sand screens) and the equivalent API 19SS. End-users audit incoming wire wrap screens before installation. Defects caught upstream cost a fraction of defects caught downhole.

Reference standards

Aligned with industry norms

ISO 17824

Petroleum and natural gas industries — Downhole equipment — Sand screens (international reference for sand control screens design and acceptance, applies to wire wrap, direct wrap and wedge wire filter screens)

API 19SS

American Petroleum Institute — Sand control screens (US / global O&G equivalent of ISO 17824, covers wire wrap and wedge wire screen acceptance)
